Introduction: Creality CR-10 S5 3D Printer
The Creality CR-10 S5 features large 3D printing dimensions of 500 mm x 500 mm x 500 mm. These dimensions make the CR-10 S5 model the largest 3D printer from the CR-10 series. Apart from its dimensions, this 3D printer solely inherits all the significant features of the Creality CR-10 3D printer. Let’s have a good overview of this 3D printer:
3D print large-sized objects
As mentioned above, the Creality CR-10 S5 allows you to 3D print large-sized objects (Maximum 500 mm x 500 mm x 500 mm). Therefore, you can 3D print large-sized objects that require splitting and assembling. You can also print more highly-complex 3D printing prototypes and models whose possibility is out of the question with the smaller 3D printers.
Support for Resume 3D Printing
The Creality CR-10 S5 3D printer supports resuming 3D printing functionality after interruption. This interruption can be due to power outage, filament runout, 3D printing glitch, user interruption, and overheating. Any of these scenarios may happen, and the resume functionality saves time, effort, and cost.
Low Noise 3D Printing Operations
The Creality CR-10 S5 3D printer offers a calm and quiet working ambiance due to its low-noise 3D printing. It primarily involves a linear bearing system for the 3D printing process that is less noisy. It has a noise level of 50 decibels which is always an acceptable level for a healthy working environment.
Filament Runout Sensor
Another key feature of the Creality CR-10 S5 is the filament runout sensor. The sensor determines the filament flow and feeding status into the nozzle. If the filament runs out or breaks, the sensor alerts the user with a blue LED light indicator. This helps to save time, effort, and overall project execution.
Double Spindle Motor
The double spindle motor is another core characteristic of the Creality CR-10 S5 3D printer. Also known as the dual-shaft stepper motor, it offers more stability and precision in 3D printing. The CR-10 S5 integrates a 42-40 double spindle motor on its S-axis and a 42-60 double spindle motor on its Y-axis. Moreover, they also improve the 3D printing speed by offering more torque and speed control altogether.
Linear Bearing system
The linear bearing system feature makes the Creality CR-10 S5, an accurate, precise, and easy-to-maintain 3D printer. These bearings allow much smoother movement of the print head and print bed, resulting in high-quality 3D output. Moreover, the linear bearing system eliminates any chances of layer shifting or wobbling during 3D prinitng. Lastly, linear bearing systems have easier maintenance because of their easier cleaning and lubrication.
Creality CR-10 S5, is the largest Creality 3D printer, with a print volume of 500 x 500 x 500mm.
It’s basically a supersized CR-10 and has a very similar set of features to the original CR-10. If you need to print 500mm objects, the CR-10 S5 is really the only affordable choice, and it’s a good printer that has worked reliably for us.
Resume Printing after power-off: CR-10S S5 could resume prints after a power outage or lapse occurs.
Easy and Quick Assembly: only 10 minutes, need to install the Z v suite in XY platform, they can easily install.
Linear Bearing System: profile+pulley=zero gap fit, newest v-slot, bring high accuracy and low noise printing.
Precision Pulley moving parts: imported polymer material processing, wear a long time.
Industrial-grade Circuit Board: can print for 200 hours without pressure, with mature technology and stable performance.
Product parameters:
Build volume: 500 x 500 x 500 mm
Frame dimensions: 690 x 800 x 715 mm
Print head: Single nozzle
Nozzle size: 0.4 mm
Max. hot end temperature: 260 ℃
Max. heated bed temperature: 60 ℃
Print bed material: Borosilicate Glass Build Plate
Frame: Aluminum
Bed leveling: CR Touch Leveling
Connectivity: SD card, USB
Print recovery: Yes
Filament sensor: Yes
Camera: No
Filament diameter: 1.75 mm
Third-party filament: Yes
Filament materials: PLA Consumer materials (ABS/PETG will require a higher hotbed temperature and in a sable condition. For the CR-10S5, as for the large build volumn, the heat dissipation rate of the hot bed will also be correspondingly faster. We will recommend the PLA for a easily printing.)
Recommended slicer: Cura, Simplify3D, Repetier-Host
Operating system: Windows, Mac OSX, Linux
File types: STL, OBJ, AMF
Creality Warranty Policy
- A 3-month limited warranty applies to vulnerable parts, i.e., module, flat belt, glass platform, etc.
- No Warranty for the Product Gift (Storage card, Card Reader, Wrench, Pliers, Scraper Knife. etc.)
